Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment

Name: Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment
Brand: BOYU
Price: 1 USD

Wholesale Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment from china suppliers

Brand Name : BOYU

Model Number : TY180-37

Certification : ISO9001

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 100sets/month.

Delivery Time : 15~25 days

Packaging Details : Container

Type : Puller Machine For Transmission Line

Bull-wheel diameter : 750mm

Groove number : 10

Max rope diameter : 28mm

Max diameter of rope reel : 1400mm

Overall dimension (length*width*height) : 5000x2300x2500mm

Max pull : 190kN

Diesel : 325hp Euro III, 4-stroke cycle, turbo-charged

Contact Now

TY180 Conductor Stringing Equipment Puller Machine For Transmission Line Max Continuous Pull 180kN

Bull-wheel diameter	750mm
Groove number	10
Max rope diameter	28mm
Max diameter of rope reel	1400mm
Total weight	6700kg
Overall dimension (lengthwidthheight)	5000x2300x2500mm
Max pull	190kN
Max continuous pull	180kN
Speed at max pull	2.5km/h
Max speed	6km/h
Pull at max speed	75kN
Engine	Cummins
Hydraulic pump	German Rexroth
Main motor	German Rexroth
Speed reducer	German Rexroth
Tail bracket hoisting motor	American Eton
Hydraulic meter	German
Operating handle	German Rexroth
Diesel	325hp Euro III, 4-stroke cycle, turbo-charged
Cooling system	liquid
Electrical system	24V

Transmission Line Puller Max Continuous Pull 180kN Conductor Stringing Equipment

Other Models

Model		TY40	TY60	TY120	TY150	TY220	TY280	TY380
Max intermittent pull	KN	40	60	120	150	220	280	380
Max continuous pull	KN	30	50	100	120	180	250	350
Speed at max pull	km/h	2.5	2.5	2.5	2.5	2.5	2.5	2.5
Max speed	km/h	5	5	5	5	5	5	5
Pull at max speed	KN	20	25	50	60	90	120	170
Diesel	kw(hp)	77(103)	77(103)	129(173)	129(173)	239(320)	298(400)	440(590)
Cooling system		Water	Water	Water	Water	Water	Water	Water
Electrical system	V	24	24	24	24	24	24	24
Bull-wheel diamete	mm	400	450	600	600	760	960	960
Groove number		7	7	10	10	10	11	11
Max rope diameter	mm	16	18	24	24	30	38	38
Max diameter of rope reel	mm	1200	1400	1400	1600	1600	1600	1900
Total weight	kg	3000	3500	4800	5500	6800	12800	13600

Company Profile

Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents.
Our company has a total area of 42800 square meters, having formed four series products:

►Electric power construction tools

►Nonmetallic galvanized the production equipment (Achieved high-tech products)

►Numerical control machine

►Low voltage no power-arc furnace compensation system

Our Certificate

Our company has passed CE certification.

Our company has passed ISO9001 certification.
